5094-OW8I and 5094-OW8IXT Digital 8-point Isolated Relay Output Modules
This figure shows a wiring diagram for the 5094-OW8I and 5094-OW8IXT modules. You must connect a 24V DC power source to the left
SA+/– terminals to provide field-side power.
5094-OW8I and 5094-OW8IXT Wiring Diagram。
