5094-IJ2I and 5094-IJ2IXT 2-channel Isolated Frequency Standard Input Modules
These figures show wiring diagrams for the 5094-IJ2I and 5094-IJ2IXT modules. You must connect a 24V DC power source to the left SA+/–
terminals to provide field-side power.
This figure shows a wiring diagram for the 5094-IJ2I and 5094-IJ2IXT modules connected to a magnetic pickup sensor.
